Course Syllabus
PRACTICAL ARCHITECTURAL & ENGINEERING DELIVERABLES
Vastu Shastra Planning: Room orientation, directional alignment &
energy layout design
Submission Drawings: Municipal authority approval layouts with
sanction compliance
Structural Centerline Plan: Column grid layout, foundation footing &
marking plans
Architectural Sections & Elevations: Cross-sectional details & Front
elevation modeling
Utility Plans: Firefighting & safety layouts, Staircase detail designs
(Riser/Tread)
Detailed Interior Schedules: Furniture placement layout, Door &
Window dimension schedules
FREE INCLUDED BENEFITS
Color & 2D Block Libraries: 1000+ Ready
Architectural Blocks & Color Hatch Symbols
1-Year Online Access: Full access to
Recorded Masterclasses & HD Tutorials
Lifetime Offline Training: Free lifetime
physical doubt-clearing & practice lab access
Career Guidance: Industry certification &
- portfolio creation support
MODULE 1: Interface & Basics Setup
- Introduction to CAD
- User Interface
- File Management
- Drawing Setup
MODULE 2: 2D Drafting & Drawing Tools
- Core Line Work
- Geometric Shapes
- Complex Objects
MODULE 3: Precision Drafting & Viewing Controls
- Object Snaps
- Tracking Tools
- Navigation Tools
MODULE 4: Object Modification Tools
- Basic Editing
- Duplication Techniques
- Trimming & Refinement
MODULE 5: Object Properties & Layer Management
MODULE 6: Insert Tab & Content Reuse
- Blocks Creation & Insertion
- External References (XREF)
- Raster Image Reference & PDF Import
- Point Cloud Integration
- OLE Objects & Hyperlinks
- Content Palette & DesignCenter
MODULE 7: Annotation & Dimensioning
- Text & Text Styles
- Dimensions & Dimension Styles
- Multileaders & Leader Styles
- Hatching, Gradient & Solid Fill
- Tables & Data Extraction
- Revision Clouds
- Annotative Scaling
MODULE 8: Dynamic Blocks & Attributes
- Block Attributes
- Dynamic Block Parameters & Actions
- Visibility States
- Block Editor Environment
MODULE 9: Express Tools
- Express Text Tools (Arc-Aligned Text, Enclose in Object, Text Mask, Convert Text to Mtext)
- Express Modify Tools (Move/Copy/Rotate, Stretch Multiple, Extended Trim)
- Express Layout Tools (Align Space, Export Layout)
- Express Dimension Tools (Reset Dim Text, Auto Number)
- Express Draw Tools (Breakline Symbol, Superhatch)
- Express Tools Utilities (Command Alias Editor, System Variable Editor)
MODULE 10: Layouts, Viewports & Plotting
- Paper Space vs. Model Space
- Layout Management
- Viewports & Viewport Control
- Plotting, Publishing & Batch Plotting
MODULE 11: Advanced 2D Techniques & Utilities
- Parametric Constraints
- Inquiry & Measurement Commands
- Purge, Audit & File Maintenance
- Customization & Tool Palettes
MODULE 12: 3D Basics & Modeling
- 3D Interface Setup
- User Coordinate System (UCS)
- 3D Solid Primitives
- Creating Solids from 2D
- Boolean Operations
- 3D Modifications
- 3D Rendering & Output
